hydraulic plate shear machine QC11Y-12X3200
Using three-point rolling guide pulley can eliminate the support gap, and increase cutting precision.
Shearing angle can be adjusted within a certain range, which can reduce the shearing deformation of sheet metal and can shear much thicker sheet metal.
The shearing stroke can be adjusted at will ,which raise the working efficiency and realize the function of partition cutting.
The back gauge is designed manual lifting function, which makes operating convenient and lubrication reliable.
Plug in hydraulic system can make oil temperature become high slowly ,meanwhile it enhance the reliability and safety operation of machine.
Standard machine is installed MD-100 controller and PLC. Adjustment of shearing counting, back gauge, shearing angle and blade gap is simple and convenient.
DAC310 and DAC360 CNC controllers both are available upon request.

1.All steel welded structure,vibrating treatment of ageing for removal of internal stress,with good rigidity and stability.
2.Intergrated hydraulic transmission system,with good reliability.
3.Triple support rolling guide raikl to eliminate gaps of support and enhance shearing quality.
4.Mechanical rear stopper with manual fine tuning,and digital indication.
5.Clearance in between shearing blades adjusted by hand wheel to be quickly.accurate and convenient.
6.Rectangular blades with four cutting edges to prolon working life,adjustable shearing angle to reduce deformation of the sheet.
7.Upper blade holder has inward tilting struction to facilitate material feed in and also enhance of the work piecision.
8.Function of shearing in section,function of aligning with light
9.Optional:rear material holding device( or for other chice)
